0-75W Trailing edge/Leading Edge Slide Foot Dimmer Switch for LED lights
Model: QE-FP-150W-001
✓ Voltage: 90-120VAC /200-240VAC
✓ LED Load: 2-75W
✓ Halo, Incandescent Load: 10-150W
✓ Dim Type:R.C- trailing edge dimmer
✓ Error LED Indicator Function
Green-Work Normal
Yellow-Overload
Red--- Short circuit
✓ Auto reactivate overload / short circuit protection
✓ Intertek CE( EMC LVD) RoHS Reach
✓ Memory position for the last setting
✓ Smooth dimming function
✓ 0-100% dimming range
✓ Great compatibility
Certificates:
Features
Error LED Indicator
Light up when power on:
Green light- Wiring and loading well.
Red light- 1. Short-circuit problem happened in the connection.
2. Wrong operation warning- The user didn’t Switch off electricity before changing loading lamp.
Yellow Light- Totally loading lamp’s power consumption is beyond the the dimmer Maximum load limited,kindly lower the lamp Qty or Bulb Power .
Auto Resettable Short Circuit Protection
Replace the traditional fuse design, resettable protection make the dimmer will survive in wrong wiring or failure load. when problem is fixed and reset, the dimmer will keep working as normal
Specifications
| General | |
| Model No. | QE-FP-150W-001 |
| Product Name | 0-75W Trailing edge/Leading Edge Slide Foot Dimmer Switch for LED lights |
| Hal/INC Load Watt | 200-240V |
| LED Load Watt | 2-75W |
| Dimming Type | Trailing Edge |
| Protect Function | Resettable Short Circuit/Overload/Overheat Protect |
| Error Indicator | Yes, Green-Normal,Yellow-Overheat,Red-Short circuit |
| Body Material | ABS+PC |
| Product Size | L 60 x W 102 x H 35.2 mm |
| Color | White |
| Net Weight | 92g |
| Warranty | 3 Years |
